1.The characteristics of the High Rise Prefabricated Steel Structure Frame Tower for Galvanized Water Tank
(1)the steel plate assembly is embedded in the concrete foundation at the bottom to form the tower foundation,
(2)the steel structure of the tower body set on the tower foundation is assembled,
(3)a water tank base is set on the top of the tower,
(4)the water tank is placed on the base of the tank.
(5)Each tower standard section is composed of space structures such as columns, trusses, gauges, and diagonal braces.
(6)This utility model assembly structure makes the construction fast and convenient, the construction period is short, and the structure is stable. The reusable performance of the steel structure effectively avoids the waste of raw materials.
2. Specification of High Rise Prefabricated Steel Structure Frame Tower for Galvanized Water Tank
Main steel frame | Hot dipped galvanized H steel, square tube, steel angle, steel pipes and etc |
Connecting | Anchor bolt, high-strength bolt , common bolt |
Packing | Pallet & Loaded into 40HQ shipping container |
Drawing | CAD/ PKPM/ Tekla |
Installation | Provide full set of drawings and video to direct installation;Engineer are able to stay at site to direct construction |
3. Product details of High Rise Prefabricated Steel Structure Frame Tower for Galvanized Water Tank
4.Why Qingdao Xinguangzheng Steel Structure Group for High Rise Prefabricated Steel Structure Frame Tower for Galvanized Water Tank?
