Steel Prefabricated Houses is a new type of light steel structure building system formed from a main steel framework comprised of H section, Z section and U section steel components, the roof and walls utilizing a variety of panels and other components such as windows, doors.
| Quantity: | |
|---|---|
1. Production introduction of 3 sided red commercial steel building with concrete slab
Steel Prefabricated Houses is a new type of light steel structure building system formed from a main steel framework comprised of H section, Z section and U section steel components, the roof and walls utilizing a variety of panels and other components such as windows, doors.
2. Specification of 3 sided red commercial steel building with concrete slab
Item Name | Materials Characteristics | Material Grade | Surface Treatment |
Steel Column | H shape,Box,Steel Pipe,Hot tolled sheet | Q235B,Q345B | Paint or Hot dip Galvanized |
Steel beam | H shape,Box,Steel Pipe,Hot tolled sheet | Q235B,Q345B | Paint or Hot dip Galvanized |
Steel Bracing | Steel Rod,Steel Pipe,Angle Steel | Q235B,Q345B | Paint or Hot dip Galvanized |
Steel Purlin | C or Z purlins(Thickness1.8mm~3.0mm) | Q235B,Q345B | Hot dip Galvanized |
External Wall panels,Roof panels | Single colorful corrugate steel sheet,sandwich panels with EPS,Rock wool,PU. | Galvanized Steel+Painting | Alu-zn 150g, Fluorocarbon pain |
Steel buildings Door | Sliding or Rolling door | Steel or Aluminum sheet | Paint or Hot dip galvanized |
Steel buildings Windows | Aluminum alloy-Glass,Aluminum alloy-shutter | T=1.0-2.0mm | Alloy |
Sky lighting panels | FRP T=1.5mm-1.8mm | Coefficient of thermal expansion:2.2x10-5/cm | Light Tranmitar 85% |
Ventilator | Turbine ventilator on a ridge | Steel,Stainless steel ,PC | Paint or Hot dip Galvanized |
Gutter | Galvanized steel plate,Stainless steel plate | T=2.0mm | Hot dip galvanized |
Downpipe | PVC pipe,color steel pipe Y=0.5mm | Dia110mm | paint |
High Bolt | Ordinary ,High strength | 10.9S,4.8S | Hot dip galvanized,Steel |
Ground bolts | Steel RodM24,M27,M30,M33,M39,M42 | 10.9S | Steel |
3. Product feature and application for 3 sided red commercial steel building with concrete slab
a. Fast assembled steel construction, easy installation, quickly finished.high strength, stable..
b. It can be recycled.environmental protection, maintenance earthquake, water proofing, energy conserving.
c. It can be workshop and customize design
d. Steel structure construction is light weight, high strength, large span and can improve higher space efficiency.;
c. H section is welded by automatic streamline at the plant, is connected at site by high strength bolts.
4. Product details of 3 sided red commercial steel building with concrete slab
6. Delivery, shipping and service for 3 sided red commercial steel building with concrete slab
Shipped in 30 days after drawing confirmed, packed with steel pallets and loading into shipping container.
7. FAQ for design and quotation
Our excellent design team will design the 3 sided red commercial steel building with concrete slab for you. If you give the following information
a. Location (where will be built? ) _____country, area
b. Size: Length*width*height _____mm*_____mm*_____mm
c. wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
d. snow load (max. Snow height)_____kn/m2, _____mm
e. anti-earthquake _____level
f. brick wall needed or not If yes, 1.2m high or 1.5m high
g. thermal insulation If yes, EPS, fiberglass wool, rock wool, PU sandwich panels will be suggested; If not, the metal steel sheets will be OK. The cost of the latter will be much lower than that of the former.
h. door quantity & size _____units, _____(width)mm*_____(height)mm
i. window quantity & size _____units, _____(width)mm*_____(height)mm
j crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m
