Steel Warehouse Design, fast assembly speed and short construction period. Steel structure is one of the most industrialized structures. The demolition of Steel Warehouse almost does not produce construction waste, and the steel can be recycled.
| Quantity: | |
|---|---|
1.Production introduction of Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
Steel Warehouse Design is a new type of light steel structure building system formed from a main steel framework comprised of H section, Z section and U section steel components, the roof and walls utilizing a variety of panels and other components such as windows, doors, and cranes.
2.Specification of Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
Item | Materials | Remark |
Steel Frame | 1.H section column and beam | Q345 steel, paint or galvanization |
| 2.wind resistant column | Q345 steel,paint or galvanization |
| 3.Roof purlin | Q235B C/Z section galvanized steel |
| 4.Wall purlin | Q235B C/Z section galvanized steel |
Supporting system | 1.Tie bar | Q235 round steel pipe |
| 2.knee brace | angle steel L50*4,Q235 |
| 3.roof horizontal bracing | φ20,Q235B steel bar, paint or galvanized |
| 4.column vertical bracing | φ20,Q235B steel bar, paint or galvanized |
| 5.purlin brace | Φ12 round bar Q235 |
| 6.knee brace | angle steel, L50*4,Q235 |
| 7.casing pipe | φ32*2.0,Q235 steel pipe |
| 8.gable angle steel | M24 Q235B |
Roof and wall protecting system | 1.Wall and roof panel | corrugated steel sheet/sandwich panel |
| ||
| 2.self tapping screw | |
| 3.Ridge tile | color steel sheet |
| 4.gutter | color steel sheet/galvanized steelstainless steel |
| 5.down pipe | |
| 6.corner trim | color steel sheet |
Fastener system | 1.Anchor bolts | Q235 steel |
| 2.Bolts | |
| 3.Nuts |
3.Product feature and application for Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
a. Fast assembled steel construction, easy installation, quickly finished.high strength, stable..
b. It can be recycled.environmental protection, maintenance earthquake, water proofing, energy conserving.
c. It can be workshop and customize design
d. Steel structure construction is light weight, high strength, large span and can improve higher space efficiency.;
c. H section is welded by automatic streamline at the plant, is connected at site by high strength bolts.
4.Product details of Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
5.Product Certification of Steel Structure Company
6.Delivery, shipping and service for Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
Shipped in 30 days after drawing confirmed, packed with steel pallets and loading into shipping container.
We reply each inquiry within 24 hours
A.Develop and make new parts according to customers' requirements and detailed information.
B.Provide service of designing, engineering, manufacturing and installation.
C.Our expert technicians can help you to assemble the project at site.
D.If you need ,we can provide you guide construction installation abroad for modern design Steel Warehouse . We have a professional installation team.
7.Company Information for Low Cost And Fast Assembling Prefabricated Steel Warehouse Design:
Main products : industrial door and window, steel structure building ( including chicken farm , warehouse , workshop , hangar , garage and so on ) . prefab house , container house .
Staff : 100 engineers and 600 production workers .
Area : More than 24000 sqm .
Product Capacity : 1200 TON per mouth.
8.FAQ for design and quotation of Low Cost And Fast Assembling Prefabricated Steel Warehouse Design
Our excellent design team will design the Steel Warehouse Design for you. If you give the following information
a. Location (where will be built? ) _____country, area
b. Size: Length*width*height _____mm*_____mm*_____mm
c. wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
d. snow load (max. Snow height)_____kn/m2, _____mm
e. anti-earthquake _____level
f. brick wall needed or not If yes, 1.2m high or 1.5m high
g. thermal insulation If yes, EPS, fiberglass wool, rock wool, PU sandwich panels will be suggested; If not, the metal steel sheets will be OK. The cost of the latter will be much lower than that of the former.
h. door quantity & size _____units, _____(width)mm*_____(height)mm
i. window quantity & size _____units, _____(width)mm*_____(height)mm
j crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m
